ICS Triplex T8461 Digital Output TMR | 40 Ch 48Vdc Trusted Module

Description Quick Overview ICS Triplex T8461 = 40-channel Digital Output TMR Module. Works with Trusted TMR System for safety-critical control. Output: 48 Vdc, 0.75A per channel, 6A per power group. Certified for ordinary and hazardous locations (ATEX/IECEx). Key Features Fault-tolerant, fully triplicated circuit design. 5 independent power groups (8 outputs each). Electronic latching short circuit protection. Automatic output short circuit protection. Sequence of Events: 1ms resolution, ±0.5ms accuracy. Self-test every 2 minutes. Optional line monitoring available. Technical Specifications (Tree View) Manufacturer & Model Brand: ICS Triplex Model: T8461 Series: Trusted TMR System Type: Digital Output TMR 48 Vdc 40 channel Power Supply Ratings System supply: 20 – 32 Vdc Power consumption: 27 W Field supply at 24V (0.75A/ch): 18W System supply (24V): 22W Input/Output Ratings Output voltage range: 18 – 58 Vdc Current per channel: 0.75A continuous Current per power group: 6A Minimum on-state load: 25mA Off-state resistance: 33kΩ (effective leakage) On-state resistance: 0.6Ω Capacitance Load (Important) Pre-release 3.5: 30-55uF Release 3.5: at least 3500uF at 0.75A Flashing/pulsing loads: Use Release 3.5 Performance & Timing Turn-on/off delay: 0.5ms Sample update time: 0.5ms Event resolution: 1ms Time-stamp accuracy: ±0.5ms
